ISO9001 250m/Min Cartons Printing Inspection Machine For Color Boxes

ISO9001 250m/Min Cartons Printing Inspection Machine For Color Boxes

Product Details:

Place of Origin: China
Brand Name: FOCUSIGHT
Certification: ISO9001/CE
Model Number: FS-SHARK-650

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Plywood
Delivery Time: 60 days
Payment Terms: L/C, T/T
Supply Ability: 20 Per Month
Get Best Price Contact Now

Detail Information

Maximum Size: 600mm×450mm Minimum Size: 100mm×100mm
Speed: 250m/min Power: 15KW
Paper Weight: 120~700 GSM Machine Mechanical Size: 6950mm (L) × 3650mm (W) × 2200mm (H)
Machine Weight: 4.5 Tons
High Light:

cartons Printing Inspection Machine

,

250m/min Printing Inspection Machine

,

ISO9001 Printing Inspection Machine

Product Description

Retail Packaging Printing Inspection System, FOCUSIGHT-SHARK-650 Model for Folding Cartons





MODEL-FS-SHARK 650-Printing Quality Inspection System

0% Chance for Defected Cartons

  • High-grade printing Quality control for all types folding cartons / pharmceuticals packaging / color boxes / tags / labels / cigarette blanks / surface defects etc.
  • Up to three top cameras, one reverse side camera and area cameras
  • The unique lighting system enables the inspection of even highly reflective substrates
  • Focusight inspection machine allows you to offer your customers quality assurance for packaging products with high added value such as luxury goods and pharmaceuticals.
  • Focusight combines LED lighting technology and 4K or 8K camera system with high-performance data processing and image analysis software,
  • This technology checks the quality of carton blanks at a speed of up to 250 m / min.
  • It gives you reliable control of finishes such as hot foil application, holograms, embossings or coating patterns.

Technical Data

Specifications FS-SHARK-650
Paper Type / GSM 120 ~ 700 GSM
Maximum speed 250m / min
Maximum output 70,000 s / h-90,000 s / h
Maximum sheet size 600mm × 450mm
Minimum sheet size 100mm × 100mm


DEFECT DETECTION



Defect Details Defect Size and Detection
Minimum defect size (as a point) 0.10mm 2 (Contrast 20DN)
Minimum defect size (as a line) 0.1mm X 5mm (Contrast 20DN)
Minimum detection area of ​​hot stamping 0.10mm 2
Print Mis-Registration detection ± 0.10mm
Die-cutting deviation detection ± 0.10mm (Contrast 20DN)
Local color difference detection E 3
Barcode detection Reading frame, error code, repeated code
Characters detection Wrong word, leak word, corresponding to bar code
Appearance detection Spot, broken line, white & black bracing wire, ink leak, warp, skew
Two dimensional code detection Two dimensional code recognition

Object of Inspection (the kind of Detectable defects on Carton s)

DEFECT TYPE CAMERA TYPES
COLOUR CAMERA ANGLE CAMERA SURFACE CAMERA REVERSE CAMERA
PRINT MISS
DIE- CUT OUT
MIS-REGISTRATIONS
DARK SHADE
LIGHT SHADE
SHADE VARIATION
INK SCUM
DIRTY
WATER DRIPS
SMEARS
BARCODE
SET OFF
HICKEYS
SMUDGY PRINTING
PRINITING WASTE
SCRATCHES
INK SCRATCHES
FOIL MISS / OUT
BRAILLE MISS / OUT
EMBOSSING MISS / OUT
LAMINATION DEFECT
IMPROPER VARNISH
UV TEXTURE
WRINKLE DEFECT
FINGER MARK
HOLOGRAM FOIL DEFECT
REVERSE SIDE TEXT DEFECT
DUST OR INSECTS
CREASING LINE REVERSE SIDE
SCRATCHES IN BACKSIDE
REVERSE SIDE DIRT MARKS
Among them: can be checked, partially can be checked, can't be checked



Service Support:

  • The warranty of our machine is 12 months and service are available lifelong.
  • Our expert will answer any inquiry within 24-48 hours, and it will be solved as soon as possible.
  • We can send enough technicians to the Buyer's company for installation and testing the machines.
  • We supply the complete technical documents and the relative drawings of the electric components which were written in English.
  • 24*7 Online Support

FAQs



Q: What its principle of this machine? Is this offline or online?

A: It takes few good cartons as standard, scans it using High Resolution CCD cameras, creates the template and inspects the other cartons for good and defected ones. The machine is offline type.

Q: What is the maximum speed of the machine?

A: 250 meters / min (Can vary depending on the job size)

Q: Do you have a Double Sheet sensor? If double sheet comes between the production what will happen?

A: Yes, it has Ultrasonic Double Sheet detector. If double sheets detect by sensor during production both cartons will be rejected.

Q: Can we adjust the tolerance level in different regions of the carton to enable differentiation between critical & Non-critical parameters?

A: Yes, we can adjust the tolerance level for every regions of the cartons depending upon QC requirements.

Q: Can we generate a Defect report (MIS REPORT) that can be downloaded to a USB for each job?

A. Yes, we can have a summary defect report for every job with defect images and other details.
