120m / Min Packaging Vision Systems , 10KW Focusight Inspection Machine
Product Details:
| Place of Origin: | China |
| Brand Name: | FOCUSIGHT |
| Certification: | ISO9001/CE |
| Model Number: | FS-GECKO-200 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood |
| Delivery Time: | 60 Days |
| Supply Ability: | 20 Machines/Month |
|
Detail Information |
|||
| Name: | Single Sided Inspection Machine | Paper Adaptability: | White Card And Paper |
|---|---|---|---|
| Model: | FS200-GECKO | Total Power: | 10KW |
| High Light: | printing inspection machine,vision inspection equipment |
||
Product Description
Focusight Inspection System for Small 200mm Size White and Grey Card Battery Tags
Product Technical Specifications
—FS200-GECKO-P2N2
- Machine Configuration
| Product Name | Product Model | Paper Adaptability |
| Single sided Inspection Machine | FS200-GECKO | White card and paper |
- Machine configuration and function parameters
| Type | Product Type | Description |
| Tag | 3 or More | Gray card and White card tags |
2.1 Machine configuration
| Content | Configuration Details | Qty | Functions Description | √/X | |
| Detection system configuration | Positive Direct Station | Imported high speed RGB color 4096 pixel Scan camera | 1 |
|
√ |
| Imported optical imaging lens | 1 | √ | |||
| Dedicated strip light source | 1 | √ | |||
| High-speed image processing computer workstation (including high-speed image acquisition processing card) | 1 | √ | |||
| Front Oblique Station | Imported high speed RGB color 4096 pixel Scan camera | 1 |
|
√ | |
| Imported optical imaging lens | 1 | √ | |||
| Dedicated oblique light source | 1 | √ | |||
| High-speed image processing computer workstation (including high-speed image acquisition processing card) | 1 | √ | |||
| Reverse Direct Station | Imported high speed RGB color 4096 pixel Scan camera | 1 |
|
√ | |
| Imported optical imaging lens | 1 | √ | |||
| Dedicated strip light source | 1 | √ | |||
| High-speed image processing computer workstation (including high-speed image acquisition processing card) | 1 | √ | |||
| Reverse Reflection Station | Imported high speed RGB color 4096 pixel Scan camera | 1 |
|
√ | |
| Imported optical imaging lens | 1 | √ | |||
| Dedicated Reflection light source | 1 | √ | |||
| High-speed image processing computer workstation (including high-speed image acquisition processing card) | 1 | √ | |||
| Detection software configuration | Print inspection module dedicated visual inspection software FSCheck V2.1.1 | 1 | √ | ||
| Mixed detection module | 1 | Mixed Code | √ | ||
| Defect detection statistics report | 1 | Document report that can count the types and quantities of defects | √ | ||
| Testing Equipment | Dedicated dust-removing sealed electric cabinet for printing inspection | 1 | Protect the detection device and it’s parts from the dust | √ | |
| 22" LCD monitor and keyboard mouse | 1 | √ | |||
| Sound and light alarm device | 1 | √ | |||
| Rear Display | 1 | √ | |||
| Mechanical Transmission Platform Structure Configuration | Suction Feeder | 1 | √ | ||
| Fish Scale Delivery | 1 | √ | |||
| Fish Scale Rejection Type | 1 | √ | |||
| Rejection Unit | 1 | √ | |||
| Electrical System | 1 | √ | |||
2.2 Technical Parameters
| Type | Parameter | |
| Max. Detection Speed | 120m/min | |
| Maximum Detection Size | 28mm Suction Head | 120mm(W) * 120mm(L) |
| 90mm Suction Head | 200mm(W)×200mm(L) | |
| Minimum Detection size | 28mm Suction Head | 30mm(w)×50mm(L) |
| 90mm Suction Head | 120mm(W)×120mm(L) | |
| Paper Weight | 150～350g/㎡ | |
| FOV | 220mm | |
| Imaging Accuracy (mm) |
Front imaging accuracy: 0.054mm * 0.075mm (4K camera) Front imaging accuracy: 0.054mm * 0.15mm (4K camera) Reverse imaging accuracy: 0.054mm * 0.075mm (4K camera) Reverse imaging accuracy: 0.054mm * 0.15mm (4K camera) |
|
| Conventional defect detection (when the defect contrast is greater than 40) |
1. Minimum detection area for defects such as missed prints and dirty spots: ≥0.15 mm² 2. Overprint deviation detection: ≥0.2mm 3. Die cutting deviation detection: ≥0.2mm 4. Cable: horizontal or vertical cable with width more than 0.1mm wide vertically or 0.2mm wide horizontally, length greater than 15mm, and contrast greater than 40 levels can be detected; 5. Local color difference detection ΔE≥3ΔELab |
|
| Mechanical Dimension | 4.4m×2.1m×1.49m(L*W*H)standard | |
| Equipment Area | 5m×3m×1.8m(L*W*H) | |
| Weight | 2 Ton | |
| Total Power | 10KW | |
