Double Side Printed Tag Quality Inspection System With Fully Suction Platform

Double Side Printed Tag Quality Inspection System With Fully Suction Platform

Product Details:

Place of Origin: China
Brand Name: FOCUSIGHT
Certification: ISO9001/CE
Model Number: FS-GECKO-200

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Plywood
Delivery Time: 60 Days
Supply Ability: 20 Machines/Month
Get Best Price Contact Now

Detail Information

Maximum Size: 200mm × 300mm Minimum Size: 40mm × 70mm
Speed: 150m/min Power: 10KW
Paper Weight: 150 ~ 350 GSM Machine Mechanical Size: 3650mm (L) × 1000mm (W) × 1500mm (H)
Machine Weight: 2Tons
High Light:

printing inspection machine

,

quality control equipment

Product Description

Upto 200mm Size Double Side Printed Tag Quality Inspection System, with Fully Suction Platform





Product Technical Specification-FS200-GECKO-P2N2



Full machine configuration



Project Configuration instructions Number Description of the function -Select
Detection system configuration Front direct-shooting station Imported high-speed RGB color 4096 pixel scan camera 1 General printing defects , die-cutting, Commodity code
Imported optical imaging lens 1
Dedicated bar light source . 1
High-speed image processing computer workstation (high-speed image capture processing card)) 1
Front angled position Imported high-speed 4096 cell-line scanning camera 1

Light oil bias, missing

Convex oil bias, missing

Embossed bias



Imported optical imaging lens 1
Dedicated Oblique Light Source . 1
High-speed image processing computer workstation (high-speed image capture processing card)) 1
Reverse direct-shooting station Imported high-speed RGB color 4096 pixel scan camera 1

General printing defects

die-cutting bias

Commodity code

Imported optical imaging lens 1
Dedicated bar light source. 1
High-speed image processing computer workstation (high-speed image capture processing card)) 1
Reverse reflection station Imported high-speed 4096 cell-line scanning camera 1

l Convex oil bias, missing

l embossed bias



Imported optical imaging lens 1
Dedicated Reflection Light Source. 1
High-speed image processing computer workstation (high-speed image capture processing card)) 1
Detection of software configurations Print inspection module dedicated vision inspection software FSCheck V2.1.1 1
Mix detection module 1 Mixed code
Defect Detection Statistics Report 1 Document reports that count the types and numbers of defects
Detection of supporting equipment Special dust-removal closed electric cabinet for printing detection 1 Protection detection devices and partial dust protection
22-inch LCD and keyboard mouse 1
Sound and light alarm device 1
Rear display 1
Mechanical platform configuration Mechanical transmission platform structure configuration Friction card issuer 1
Note: double-sided water-based photooil or film class, such as scratch-prone products are not within the scope of this specification agreement;
Electrostatic dust removal device 1
Fish scale syield collection mechanism 1
Fish scale satosing collection facility 1
Replica Reject Ingesta (Note 1) 1
Electrical support ingen-care system 1
Strong electrical components of mechanical platforms German SEW main motor 1 4KW Supply Host Main Drive Power
German SEW paper transfer motor 1 1.5KW supply paper cloth set drive power
Pump 2 2 units of4KW
Collectthe motor 1 0.4KW
Waste-receiving motors 1 0.4KW

Note 1: This transmission system requires the user to provide a factory concentrated gas source or an external air compressor for equipment scrap removal.



2.3 Device function parameters

Project Function parameters
Maximum detection speed 150 /
Maximum detection size 200mm )x300mm(length)( length is more than 140mm,host speed needs to be reduced appropriately) )
Minimum detection size 40mm )x70mm(length)
Adapting to paper weight 150to350g/m2
Field of view 220mm
Imaging accuracy (mm)

Front imaging accuracy (direct-shooting station):0.054mm x 0.075mm(4K camera)

Front imaging accuracy (oblique station):0.054mm x 0.15mm(4Kcamera)

Reverse imaging accuracy (direct-shooting station):0.054mm x 0.075mm(4K camera)

Reverse imaging accuracy (reflected station):0.054mm x 0.15mm(4Kcamera)

General defect detection (when defect contrast is greater than 40 levels)

1. Minimum detection area of defects such as leakage, dirty points: s0.15 mm2

2. Minimum detection area of ​​hot burn defects: .2mm2

3. Overprint bias detection:.1mm

4. Die-cutting deviation detection:.1mm

5. Pull line: can detect a horizontal or vertical pull line that is wider than 0.1mm vertical, or 0.2mm wide horizontal, more than 15mmin length, and a contrast greater than 40 levels;

6. Local Chromatic Abercheck Detection , E-3ELab

Mechanical profile size 3.65m x 1mx1.49m (L * W * H) standard
Equipment footprint 3.65m x 2mx1.8m (L * W * H)
Mechanical weight 2 tons
Full machine power 10KW
