250gsm Automated Packing Machine Cartoner High Accuracy Positioning

Product Description

Features:

1. This product is the ideal automatic equipment for the processing of fine boxes, to achieve a rule with automatic feeding of the end box, moulding box, angle box, delivery box, package forming and pressure & other functions with automatic fault alarm function.
2. The whole machine adopts PLC control system with memory function program formula design that can achieve rapid switching.
3. The whole line adopts modularity, flexibility and miniaturization design thinking. Each module can operate independently.
4. Can quickly replace the module to achieve a variety of compatible products.
5. Using mechanical positioning the accuracy can be positive and negative 0.05mm.
6. Applicable to all kinds of fine box type, especially for cigarette packaging business.

Machine Structure:

1. Bottom Box Molding Machine

• Machine with non-stop auto feeding function
• Adept with module working station composition
• Adept with Glue system small module design, offline clean-up
• Adept with sensor assistance glue system position, digital adjustment

1. Inner Box Corner Making Machine

• Machine with non-stop auto feeding function
• Adept with screw adjustment, can adjust the parameters with code reader module
• integeral and high accuracy positioning
• Easy job change module
• Simple structure and easy module

1. Coverage Molding Machine

• Machine with non-stop auto feeding function
• Adept with chain transmission mechanism
• Surface paper integeral positioning and high accuracy positioning with micrometer knob
• Implementation of each molding station
• Easy mechanical structure make the easy visual operation and maintenace
